4.14
ENTER START TIME
HOUR
00
As per period entry above.
ENTER START TIME
MINUTE
00
As per period entry above.
TIME 12:00:00
DATE 10/12/95
Temporary display of start time and date. This
must be later than the current time and date.
SET UP CAL PARM
ONE CYCLE
L ? ENTER to perform an auto cal or check
L MEASURE to return to measurement
display
Note
* The autocalibration parameters can be changed without changing the
autocalibration timing already installed by pressing the "Quit" key at the
beginning of the start date entry section.
4.10 Initiating auto calibration or auto check from keypad
An auto calibration or auto check may be initiated from the keypad by following the
procedure in Table 4.8.
Table 4.8 Initiating auto cal or check from keypad
L MENU to obtain top level menu
CALIBRATE/SETUP
ALARMS/FAULTS
L ENTER
MANUAL CAL
AUTOCAL
L ? ENTER
ENTER PASSWORD
0000
To change the value of a digit
L > or ?
To change to another digit L = or <
When the value shown is correct L ENTER
SET UP CAL PARM
ONE CYCLE
L ? ENTER
4.11 Initiating auto calibration or auto check by external contact closure
An auto calibration or auto check may be initiated by closing a switch between
PL5/11 and PL5/12. The switch must be closed for at least 2 seconds to guarantee
operation and opened before the calibration is complete.
