6.4 Displaying relay configuration
The conditions under which each relay will operate may be determined using the
procedure described in Table 6.3.
Table 6.3 Displaying relay configuration
L MENU to obtain top level menu
CALIBRATE/SETUP
ALARMS/FAULTS
L < ENTER
SET ALARM/ASSIGN
DISPLAY/UTILITY
L ? ENTER
OUTPUTS/ALARMS
DIAGNOSTICS/ID
L ENTER
RELAY
ANALOGUE
L ENTER
DISPLAY RELAY
1.3 ASSIGNED
8
or
1.3 UNASSIGNED8
L
> or ? to select the required relay
then
L ENTER
1.3 I4 Oxygen AL4
LO 0.000 %
8
or
98.00 HIGH
8
or
1.3 FAULT
8
or
1.3 CAL IN PROG8
The first allocation to this relay will be displayed,
if there are further allocations an arrow will be
shown,
L > or ? to access further allocations.
When all allocations for this relay have been
viewed
L QUIT to select another relay
or
L MEASURE to select measurement display
6.5 Displaying analogue output configuration
The configuration of each analogue output may be determined by using the procedure
described in Table 6.4.
