5.6 Defining and selecting measurement displays
Up to five measurement display screens may be defined. Each screen definition may
have up to four measurements. These screen definitions must then be selected. The
selected screen definitions may then be scrolled manually by pressing MEASURE or
scrolled automatically every ten seconds. See Table 5.9 for setting up procedure.
Table 5.9 Defining and selecting measurement displays
L EDIT to obtain window edit menu
ENTER PASSWORD
0000
To change the value of a digit
L > or ?
To change to another digit L = or <
When the number shown is correct L ENTER
SELECT SCRN/UDEF
DEFINE SCRN/VARS
To define screens
L ? ENTER
DEFINE SCREEN
NUMBER : 1
L > or ? to select the required screen number
L ENTER
SELECT 1ST UDEF
I1 O2 %
;
L
> or ? to select the required gas sensor
module
L ENTER
MORE UDEFS?
YES/NO
L ENTER to add more measurements to this
screen definition
or
L < ENTER to select another screen for
definition
When all required screen definitions have been
entered L < ENTER QUIT ENTER to obtain
select screens menu.
SELECT SCRN/UDEF
DEFINE SCRN/VARS
To select screens L ENTER
SELECT ORDER
1ST SCREEN IS : 1
L > or ? to select first screen to be displayed
L ENTER
MORE SCREENS?
YES/NO
L ENTER to select more screen definitions
L < ENTER if no further screens are required.
AUTOSCROLL ?
YES/NO
L ENTER to select auto-scrolling
L < ENTER to select manual scrolling
SELECT SCRN/UDEF
DEFINE SCRN/VARS
L MEASURE to return to measurement display.
