6.6 Displaying alarm settings
The conditions under which each alarm is configured to operate may be determined
using the procedure described in Table 6.5.
Table 6.5 Displaying alarm settings
L MENU to obtain top level menu
CALIBRATE/
SETUP
ALARMS/FAULTS
L < ENTER
SET ALARM/ASSIGN
DISPLAY/UTILITY
L ? ENTER
OUTPUTS/
ALARMS
DIAGNOSTICS/ID
L < ENTER
SELECT MEASURE
I1 Oxygen
8
L
> or ? to select required measurement.
When selected L ENTER
I1 Oxygen AL1 LO
80.00% DISAB 8
The configuration of each of the four alarms
(AL1 to AL4) is shown on two screens making
a total of eight screens to be viewed. To obtain
the next screen L >
I1 Oxygen AL1 LO
HYST 0.1% FOL ;
To obtain the next screen L >
I1 Oxygen AL2 LO
95.45% ENABL
;
To obtain the next screen L >
I1 Oxygen AL2 LO
HYST 0.3% FRZ ;
To obtain the next screen L >
I1 Oxygen AL3 LO
96.00% ENABL;
To obtain the next screen L >
I1 Oxygen AL3 LO
HYST 0.1% FOL ;
To obtain the next screen L >
I1 Oxygen AL4 HI
99.00% DISAB ;
To obtain the next screen L >
I1 Oxygen AL4 LO
HYST 0.1% FOL 9
This is the last of the eight screens
L MEASURE to return to measurement display
L QUIT to select another measurement
