6.1
SECTION 6 REVIEW
6.1 Introduction to review section
This section describes the procedures for reviewing the analyser configuration without
changing it. The only procedure which requires a password in this section is review of
the calibration history.
6.2 Displaying alarms present
If the measurement display shows the ’ALARM’ icon the number and nature of the
alarms present may be determined using the procedure described in Table 6.1.
Table 6.1 Displaying alarms present
L MENU to obtain top level menu
CALIBRATE/SETUP
ALARMS/FAULTS
L ? ENTER
DISPLAY ALARMS
ALARM HISTORY
L ENTER
I1 O2 AL1
99.98 HIGH
8
The first alarm is displayed, if further alarms are
present an arrow will be shown,
L > or ? to
access information on further alarms.
When alarms have been viewed
L MEASURE
to return to measurement display.
6.3 Displaying faults present
If the measurement display shows the ’FAULT’ icon the number and nature of the
faults present may be determined using the procedure described in Table 6.2.
Table 6.2 Displaying faults present
L MENU to obtain top level menu
CALIBRATE/SETUP
ALARMS/
FAULTS
L ? < ENTER
DISPLAY FAULTS
FAULT HISTORY
L ENTER
I1 CELL TEMP
LOW 8
The first fault is displayed, if further faults are
present an arrow will be shown, L > or ? to
access information on further faults.
When faults have been viewed L MEASURE to
return to measurement display.
