8.5

8.4 Fault diagnosis with a non-functioning display

Table 8.5 describes checks which can be made if the display is blank or not illuminated

Table 8.5 Fault finding with non functioning display

Symptoms Possible causes Recommended

action

DIM DISPLAY Improper viewing

angle

Adjust viewing angle

of display

DIM DISPLAY Edge light failed Call service engineer

NO DISPLAY Unit power is off Turn on power

NO DISPLAY Blown fuse Replace fuse

If the display is functional but a measured value field is replaced by the word ‘OVER’

the related transducer is outside its operating range, see Section 1.8.
