Shake! 350 - General Road Guidance Display

9.6 General Road Guidance
-23-
When there are left or right turns on general roads, a left or right turn
guidance arrow will be displayed on the bottom left of the screen, and
at the same time audio assist will begin.
Audio assist will be given just before, at 300 m, and at 500 m before
at turn.
In addition, at top center, the name of the intersection to be turned at
next (or when there is no intersection name the street name) will be
displayed.
Left Turn
Right
Direction
Right Turn
Left
Direction
100m 100m 100m 100m
Distance to
Goal Point
Name of street
you are on now
Estimated
Time of Arrival
Goal Direction
Line
Compass
Vehicle
Position
Current
Time
12:00
GPS Button
Zoom
Display:
From 1 km to
25 m this will
be displayed
in up to 7
steps.
Distance to
Intersection
12:05
Name of the intersection
to be turned at next
