Shark 100B User Manual

Doc# E145701 6 - 15
6: Using the Shark® 100 Meter
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
6.2.6: Using Operating Mode
Operating mode is the Shark® 100/100B/50 meter’s default mode, that is, the stan-
dard front panel display. After starting up, the meter automatically scrolls through the
parameter screens, if scrolling is enabled. Each parameter is shown for 7 seconds,
with a 1 second pause between parameters. Scrolling is suspended for 3 minutes after
any button is pressed.
1. Press the Down button to scroll all the parameters in Operating mode. The
currently “Active,” i.e., displayed, parameter has the Indicator light next to it, on
the right face of the meter.
2. Press the Right button to view additional readings for that parameter. The table
below shows possible readings for Operating mode. Sheet 2 in Appendix A shows
the Operating mode Navigation map.
NOTE: Readings or groups of readings are skipped if not applicable to the meter type
or hookup, or if they are disabled in the programmable settings.
OPERATING MODE PARAMETER READINGS
POSSIBLE READINGS
VOLTS L-N VOLTS_LN VOLTS_LN_
MAX
VOLTS_LN_
MIN
VOLTS_LN_
THD
VOLTS L-L VOLTS_LL VOLTS_LL_
MAX
VOLTS_LL_
MIN
AMPS AMPS AMPS_NEU
TRAL
AMPS_MAX AMPS_MIN AMPS_THD
W/VAR/PF W_VAR_PF W_VAR_PF
_MAX_POS
W_VAR_PF
_MIN_POS
W_VAR_PF
_MIN_NEG
VA/Hz VA_FREQ VA_FREQ_
MAX
VA_FREQ_
MIN
Wh KWH_REC KWH_DEL KWH_NET KWH_TOT
VARh KVARH_PO
S
KVARH_NE
G
KVARH_NE
T
KVARH_TO
T
VAh KVAH
