BACnet/IP, which is used by the Shark 100B meter, is a newer implementation of the
BACnet standard, which allows users to perform BACnet communication through the
Internet or Intranet.
For more detailed information, visit the BACnet website at www.bacnet.org.
7.2: Shark® 100B Meter’s BACnet Objects
The Shark® 100B meter's BACnet IP has 40 predefined objects of electrical
measurements. No programming or mapping is necessary to use the BACnet objects.
The object’s names easily identify the measurements they contain.
All of the objects, with the exception of Modbus Meter and POLL_DELAY are AI (analog
input) Object type. The following table lists each of the objects with their units of
measurement and description.
Object Name
Unit of
Measurement
Description
Modbus Meter-147222 none (Addr. 1)
POLL_DELAY AV-1 Polling Delay
VOLTAGE_LN-A
volt
Voltage A-N
VOLTAGE_LN-B volt Voltage B-N
VOLTAGE_LN-C volt Voltage C-N
VOLTAGE_LL-AB volt Voltage A-B
VOLTAGE_LL-BC volt Voltage B-C
VOLTAGE_LL-CA volt Voltage C-A
CURRENT_LN-A amp Current A
CURRENT_LN-B amp Current B
CURRENT_LN-C amp Current C
PWR_ELEC watt Total Active Power
PWR_ELEC_REACT volt-amp-reactive Total Reactive Power
PWR_ELEC_APPAR volt-amp Total Apparent Power
PWR_FACTOR --- Total Power Factor
FREQUENCY Hertz Frequency
CURRENT_NG amp Neutral Current
ENERGY_ELEC_ACCUM_REC* watt-hour Active Energy Received
