Shark 100B - Page 127

Doc# E145701 7 - 3
7: Using the Shark® 100B Meter
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
ENERGY_ELEC_ACCUM_DEL* watt-hour Active Energy Delivered
ENERGY_ELEC_ACCUM_NET* watt-hour Active Energy Net
ENERGY_ELEC_ACCUM* watt-hour Total Active Energy
ENERGY_ELEC_ACCUM_REACT_
REC*
watt-hour Positive Reactive Energy
ENERGY_ELEC_ACCUM_REACT_
DEL*
watt-hour Negative Reactive Energy
ENERGY_ELEC_ACCUM_REACT_
NET*
watt-hour Reactive Energy Net
ENERGY_ELEC_ACCUM_REACT* watt-hour Total Reactive Energy
ENERGY_ELEC_ACCUM_APPAR* watt-hour Total Apparent Energy
DEMAND_POS watt Positive Active Demand, 3-Phase,
Average Demand
DEMAND_REACT_POS volt-amp-reactive Positive Reactive Demand, 3-
phase, Average Demand
DEMAND_NEG watt Negative Active Demand, 3-
Phase, Average Demand
DEMAND_REACT_NEG volt-amp-reactive Negative Reactive Demand, 3-
Phase, Average Demand
DEMAND_APPAR volt-amp Apparent Demand, 3-Phase,
Average Demand
DEMAND_PEAK_POS watt Positive Active Demand, 3-Phase,
Max Average Demand
DEMAND_REACT_PEAK_POS volt-amp-reactive Positive Reactive Demand, 3-
phase, Max Average Demand
DEMAND_PEAK_NEG watt Negative Active Demand, 3-
Phase, Max Average Demand
DEMAND_REACT_PEAK_NEG volt-amp-reactive Negative Reactive Demand, 3-
Phase, Max Average Demand
DEMAND_APPAR_PEAK volt-amp Apparent Demand, 3-Phase, Max
Average Demand
VOLTAGE_THD-A percent Voltage A-N %THD
VOLTAGE_THD-B percent Voltage, B-N %THD
VOLTAGE_THD-C percent Voltage, C-N % THD
CURRENT-THD-A percent Current, A %THD
Object Name
Unit of
Measurement
Description
