6.4: Performing Watt-Hour Accuracy Testing (Verification)
To be certified for revenue metering, power providers and utility companies must
verify that the billing energy meter performs to the stated accuracy. To confirm the
meter’s performance and calibration, power providers use field test standards to
ensure that the unit’s energy measurements are correct. Since the Shark® 100/
100B/50 meter is a traceable revenue meter, it contains a utility grade test pulse that
can be used to gate an accuracy standard. This is an essential feature required of all
billing grade meters.
• Refer to Figure 6.5 for an example of how this process works.
• Refer to Table 6.1 for the Wh/Pulse constants for accuracy testing.
Figure 6.4: Watt-hour Test Pulse
