Shark 100B - Page 155

B: Modbus Map
Doc# E145701 MM-3
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Description
1
Format Range
6
Units or
Resolution Comments
#
Reg
Modbus Address
Hex Decimal
0BD5 - 0BD6 3030 - 3031 Negative Power Factor, 3-Ph, Minimum Avg Demand FLOAT -1.00 to +1.00
none
2
0BD7 - 0BD8 3032 - 3033 Frequency, Minimum FLOAT 0 to 65.00 Hz 2
Block Size:
34
read-onl
y
0C1B - 0C1C 3100 - 3101 Volts A-N, Maximum FLOAT 0 to 9999 M volts 2
0C1D - 0C1E 3102 - 3103 Volts B-N, Maximum FLOAT 0 to 9999 M volts 2
0C1F - 0C20 3104 - 3105 Volts C-N, Maximum FLOAT 0 to 9999 M volts 2
0C21 - 0C22 3106 - 3107 Volts A-B, Maximum FLOAT 0 to 9999 M volts 2
0C23 - 0C24 3108 - 3109 Volts B-C, Maximum FLOAT 0 to 9999 M volts 2
0C25 - 0C26 3110 - 3111 Volts C-A, Maximum FLOAT 0 to 9999 M volts 2
0C27 - 0C28 3112 - 3113 Amps A, Maximum Avg Demand FLOAT 0 to 9999 M amps 2
0C29 - 0C2A 3114 - 3115 Amps B, Maximum Avg Demand FLOAT 0 to 9999 M amps 2
0C2B - 0C2C 3116 - 3117 Amps C, Maximum Avg Demand FLOAT 0 to 9999 M amps 2
0C2D - 0C2E 3118 - 3119 Positive Watts, 3-Ph, Maximum Avg Demand FLOAT 0 to +9999 M watts 2
0C2F - 0C30 3120 - 3121 Positive VARs, 3-Ph, Maximum Avg Demand FLOAT 0 to +9999 M VARs 2
0C31 - 0C32 3122 - 3123 Negative Watts, 3-Ph, Maximum Avg Demand FLOAT 0 to +9999 M watts 2
0C33 - 0C34 3124 - 3125 Negative VARs, 3-Ph, Maximum Avg Demand FLOAT 0 to +9999 M VARs 2
0C35 - 0C36 3126 - 3127 VAs, 3-Ph, Maximum Avg Demand FLOAT -9999 M to +9999 M VAs 2
0C37 - 0C38 3128 - 3129 Positive Power Factor, 3-Ph, Maximum Avg Demand FLOAT -1.00 to +1.00
none
2
0C39 - 0C3A 3130 - 3131 Negative Power Factor, 3-Ph, Maximum Avg Demand FLOAT -1.00 to +1.00
none
2
0C3B - 0C3C 3132 - 3133 Frequency, Maximum FLOAT 0 to 65.00 Hz 2
Block Size:
34
read-onl
y
0F9F - 0F9F 4000 - 4000 Volts A-N, %THD UINT16 0 to 9999, or 65535 0.1% 1
0FA0 - 0FA0 4001 - 4001 Volts B-N, %THD UINT16 0 to 9999, or 65535 0.1% 1
0FA1 - 0FA1 4002 - 4002 Volts C-N, %THD UINT16 0 to 9999, or 65535 0.1% 1
0FA2 - 0FA2 4003 - 4003 Amps A, %THD UINT16 0 to 9999, or 65535 0.1% 1
0FA3 - 0FA3 4004 - 4004 Amps B, %THD UINT16 0 to 9999, or 65535 0.1% 1
0FA4 - 0FA4 4005 - 4005 Amps C, %THD UINT16 0 to 9999, or 65535 0.1% 1
0FA5 - 0FA5 4006 - 4006 Phase A Current 0th harmonic magnitude UINT16 0 to 65535 none 1
0FA6 - 0FA6 4007 - 4007 Phase A Current 1st harmonic magnitude UINT16 0 to 65535 none 1
0FA7 - 0FA7 4008 - 4008 Phase A Current 2nd harmonic magnitude UINT16 0 to 65535 none 1
0FA8 - 0FA8 4009 - 4009 Phase A Current 3rd harmonic magnitude UINT16 0 to 65535 none 1
0FA9 - 0FA9 4010 - 4010 Phase A Current 4th harmonic magnitude UINT16 0 to 65535 none 1
0FAA - 0FAA 4011 - 4011 Phase A Current 5th harmonic magnitude UINT16 0 to 65535 none 1
0FAB - 0FAB 4012 - 4012 Phase A Current 6th harmonic magnitude UINT16 0 to 65535 none 1
0FAC - 0FAC 4013 - 4013 Phase A Current 7th harmonic magnitude UINT16 0 to 65535 none 1
0FAD - 0FAD 4014 - 4014 Phase A Voltage 0th harmonic magnitude UINT16 0 to 65535 none 1
0FAE - 0FAE 4015 - 4015 Phase A Voltage 1st harmonic magnitude UINT16 0 to 65535 none 1
0FAF - 0FAF 4016 - 4016 Phase A Voltage 2nd harmonic magnitude UINT16 0 to 65535 none 1
0FB0 - 0FB0 4017 - 4017 Phase A Voltage 3rd harmonic magnitude UINT16 0 to 65535 none 1
0FB1 - 0FB8 4018 - 4025 Phase B Current harmonic ma
g
nitude
s
8
0FB9 - 0FBC 4026 - 4029 Phase B Volta
g
e harmonic ma
g
nitude
s
4
0FBD - 0FC4 4030 - 4037 Phase C Current harmonic ma
g
nitude
s
8
0FC5 - 0FC8 4038 - 4041 Phase C Volta
g
e harmonic ma
g
nitude
s
4
Block Size:
42
Primary Maximum Block (IEEE Floating Point)
same as Phase A Current 0th to 7th harmonic ma
g
nitude
s
same as Phase A Volta
g
e 0th to 3rd harmonic ma
g
nitude
s
THD Bloc
k
7, 13
same as Phase A Current 0th to 7th harmonic ma
g
nitude
s
same as Phase A Volta
g
e 0th to 3rd harmonic ma
g
nitude
s
