Description
1
Format Range
6
Units or Resolution Comments
#
Reg
Modbus Address
Hex Decimal
753E - 753E 30015 - 30015 User Settings Flags UINT16 bit-mapped
---g--nn srp--wf-
g = enable alternate full scale bargraph
current (1=on, 0=off)
nn = number of phases for voltage &
current screens (3=ABC, 2=AB, 1=A,
0=ABC)
s = scroll (1=on, 0=off)
r = password for reset in use (1=on, 0=off)
p = password for configuration in use
(1=on, 0=off)
w = pwr dir (0-view as load, 1-view as
generator)
f = flip power factor sign (1=yes, 0=no)
1
753F - 753F 30016 - 30016 Full Scale Current (for load % bargraph) UINT16 0 to 9999 none If non-zero and user settings bit g is set,
this value replaces CT numerator in the
full scale current calculation.
1
7540 - 7547 30017 - 30024 Meter Designation ASCII 16 char none 8
7548 - 7548 30025 - 30025 Reserved - do not use. 1
7549 - 7549 30026 - 30026 Communication port setup UINT16 bit-mapped
----dddd -ppp-bbb
dddd = reply delay (* 50 msec)
ppp = protocol (1-Modbus RTU, 2-
Modbus ASCII)
bbb = baud rate (1-9600, 2-19200, 4-
38400, 6-57600)
1
754A - 754A 30027 - 30027 Communication port address UINT16 1 to 247 none 1
754B - 754B 30028 - 30028 Reserved - do not use. 1
754C - 754C 30029 - 30029 Reserved - do not use. 1
