Doc# E145701 3 - 7
3: Mechanical Installation
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
NOTE: If mounting with the DIN Rail pro-
vided, use the Black Rubber Stoppers
(also provided). See Figure 3.10.
TO REMOVE METER FROM DIN RAIL:
Pull down on Release clip to detach the
unit from the DIN rail.
NOTE ON DIN RAILS:
DIN rails are commonly used as a
mounting channel for most terminal
blocks, control devices, circuit protection
devices and PLCs. DIN Rails are made of electrolytically plated cold rolled steel but are
also available in aluminum, PVC, stainless steel and copper.
Rubber Stoppers
Release
Clip
Figure 3.10: DIN Rail Detail
