Enjoying 3D image viewing
Preparing for the 3D glasses
Confi rm how to use the 3D glasses before watching 3D-supported images. These 3D glasses are only for use with
SHARP LCD TVs supporting 3D.
You can enjoy 3D-supported images on the TV when you wear the supplied 3D glasses or optional 3D glasses.
Supplied accessories for the 3D glasses
Part name
Power-supply terminal
• This terminal is for recharging and the supply of
power when connected to the TV.
Infrared receiver
• Receives an infrared signal sent from the TV. The
3D glasses turn off automatically after 10 minutes
if no signal is received from the TV.
Nose pad mount
• The dedicated nose pad can be mounted here
(See page 51.)
1
2
5
3D/2D/OFF switch
• This button switches between 2D and 3D modes.
LED light
• Blinks once every second when the battery power
is low.
3
4
NOTE
• Do not soil or apply stickers or other obstacles to the
infrared receiver. Doing so may block signals from the TV
and prevent the 3D glasses from working correctly.
• Interference from other infrared communications equipment
may prevent you from viewing 3D images correctly.
NOTE
• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.
3
4
5
3D glasses ( x 1)
Nose pad * (large × 1, small × 1)
Pages 50 to 53
Page 51
Glasses case ( x 1)
Cleaning cloth ( x 1)
USB cable (× 1)**
Page 52
* Use the nose pad for children as needed.
The small nose pad is already attached.
** The supplied USB cable is the recharging
cable for the 3D glasses (AN-3DG20). It
is not possible to connect it to other USB
devices.
NOTE
• Some menu items are greyed out in 3D mode. This is not a malfunction.
