Home network setup
Specifi cations – Wireless LAN
Standard IEEE 802.11a/b/g/n
Frequency Band
2400-2483.5 MHz
5725-5850 MHz
Security
Static WEP (64/128 bit key Index 1 only)
WPA-PSK (TKIP)
WPA2-PSK (AES)
Modulation
DBPSK@1Mbps
DQPSK@2Mbps
CCK@5.5/11Mbps
BPSK@6/9 Mbps
QPSK@12/18Mbps
16-QAM@24Mbps
64-QAM@48/54Mbps and above, Rx up to 300Mbps
Transmit Power and Sensitivity
Tx Output Power: (Typical)
2.4GHz
11b 17 +/- 2 dBm
11g 14 +/- 2 dBm
11n 13 +/- 2 dBm
5GHz
11a 14 +/- 2 dBm
11n 13 +/- 2 dBm
Rx Sensitivity: (Typical)
-84dBm@11Mbps
-72dBm@54Mbps
-65dBm@HT20
-62dBm@HT40
