(8) Paper select display
This shows the size of paper loaded in each tray.
For the bypass tray, the paper type appears above the
paper size.
The selected tray is highlighted.
The approximate amount of paper in each tray is
indicated by . Trays 1 to 4 can be touched to open
the same screen as when the [Paper Select] key is
touched.
☞ PAPER TRAYS (page 2-11)
(9) Number of copies display
This shows the number of copies set.
(10) [Special Modes] key
Touch this key to select special modes such as Margin
Shift, Edge Erase, and Dual Page Copy.
☞ SPECIAL MODES (page 2-37)
(11) [2-Sided Copy] key
Touch this key to select the 2-sided copying function.
☞ AUTOMATIC 2-SIDED COPYING (page 2-16)
(12) [Output] key
Touch this to select an output function such as sort,
group, offset, or staple sort.
☞ OUTPUT (page 2-31)
(13) Customized keys
The keys that appear here can be changed to show
settings or functions that you prefer.
☞ Customizing displayed keys (page 2-5)
(14) [Preview] key
Touch to view a preview image of a copy in the touch
panel before printing the copy.
☞ CHECKING A PREVIEW IMAGE OF A COPY
(Preview) (page 2-122)
Tray during paper feeding
Do not pull out a tray while paper is being fed from the tray. This will cause a paper misfeed.
Identifying the tray that is being used to feed paper
(1) While paper is feeding, the job status display of the system bar on the touch panel screen will show the number of
the tray that is being used to feed paper.
(2) The tray being used to feed paper also appears in green in the paper size display in the base screen on the touch
panel.
The screen explained in this section appears when a paper drawer, and finisher are installed. The image will vary depending
on the equipment installed.
Color Mode
Special Modes
2-Sided Copy
Output
File
Quick File
Copy Ratio
100%
Original
Paper Select
Auto
Full Color
Exposure
Auto
Tray2
Preview
1.
8½x11
1.
8½x11
Auto
8½x11
Plain
8½x11
3.
2.
4.
11x17
8½x11R
8½x14
1.
8½x11
Plain
8½x11
