8-90
SYSTEM SETTINGSâ–ºSYSTEM SETTINGS
Device IP Address (Access Point Mode)
Enter the IP address.
Channel
Select the channel to be used in wireless LAN.
Sending Output
Configure the sending output.
Bandwidth
Use this setting when the communication mode is "11n". Select the bandwidth to be used.
IP Address Distribution Range Setting
Configure the range to be used the IP address.
Wireless Setting screen (Infrastructure Mode)
If [Connection Type] is set to [Wireless (Infrastructure Mode)] and the [Setup] button is clicked, the infrastructure mode
wireless setting screen is displayed.
Configure the SSID of a wireless LAN, Security Type, Encry., and Security Key. Clicking the [Submit] button stores the
settings.
Access Point Search
Click this to search access points. When the search results are displayed, select the access point to use and click [OK].
[SSID], [Security Type], and [Encry.] are automatically applied.
SSID
Enter an SSID using up to 32 characters.
Security Type
Select a security type.
Encry.
Select an encryption type.
Security Key
Enter a security key.
Show Security Key
If it is set to ON, the security key appears.
Security Type Security Key
• WEP
• WPA/WPA2-mixed Personal
• WPA/WPA2-mixed Enterprise
• WPA2 Personal
• WPA2 Enterprise
WEP64bit: 5 characters or 10-digit hexadecimal number
WEP128bit: 13 characters or 26-digit hexadecimal number
WPA/WPA2: 8 to 63 characters or 64-digit hexadecimal number
