Sharp SF-2040 - Page 108

Sim. NO Sim. SUB Description
01
01 Optical system mirror scanning check
02 Optical system sensor state display
03 Lens movement operation check
04 Lens aging
02
01 RADF aging
02 RADF sensor state display
03
RADF individual load operation check
Motor A forward rotation
04 Motor A reverse rotation
05 Motor B forward rotation
06 Motor B reverse rotation
07 Belt clutch
08 Paper feed solenoid
09 Reverse solenoid
10 Shutter solenoid
11 Brake clutch
03
02 Sorter sensor state display
03
Sorter individual load operation check
Transport motor
04 Bin shift motor
05 Fan motor (SF-S15 only)
06 Gate solenoid
08 Staple motor (SF-S53 only)
09 Paper hold solenoid (SF-S53 only)
10 Guide bar motor (SF-S53 only)
04
02 Desk sensor check
03 Tray size switch check
04
06 Transport motor activation
07
Lift up motor rotation
08
09
10 Transport clutch activation
11
Paper feed solenoid activation
13
12
Paper feed clutch activation
14
16
17 Transport changeover clutch activation (SF-D23 only)
18 Separate clutch activation (SF-D23 only)
05
01 Operation panel display check
02 Fuser lamp check
03 Copy lamp check
04 BL/DL check
06 02 Separation pawl solenoid operation check
07
01 Warm-up time display and aging with jam detection
04 Warm-up disabled
06 Intermittent aging
07 Intermittent aging without jam
08
01 Developer bias check
02
MHV (Charge), grid check
ME
03 Photo
04 TSM
06 THV (Transfer) check
07 SHV (Separation) check
09
02 ADU sensor state display
03 ADU trail edge plate aging
04 ADU alignment plate aging
05 Gate solenoid operation check
10 ** Toner motor aging
14 ** Cancel of troubles except U2, H2, H3, H4
16 ** Cancel of U2 trouble code
17 ** PF trouble cancel
20 ** Maintenance counter clear
21
01 Maintenance cycle setting
02 Setting of domestic mini maintenance for black copy kit
22
01 Maintenance counter display
02 Maintenance preset counter display
03 Jam memory display
8 – 2
