Sharp UP-700 - Page 221

219
Removing the journal paper roll
1. Remove the printer cover.
2. Press the
JOURNAL
key to advance the journal paper until its
printed part is out of the way.
3. Cut the paper and remove the take-up spool.
4. Cut the paper behind the printer and near the paper roll.
5. Press the
JOURNAL
key until the paper remaining in the printer
comes out completely.
6. Remove the paper roll from the back of the printer.
NOTE
Do not pull the paper through the printer.
7. Remove the outer side of the take-up spool as shown on
the left.
8. Remove the printed journal roll from the take-up spool.
Area to cut
