Sharp XV-Z17000 User Manual

-28
Image Projection (Continued)
Freezing a Moving Image
1
Press FREEZE.
The projected image is frozen.
2
Press FREEZE again to return to
the moving image from the cur-
rently connected device.
Auto Sync
(Auto Sync Adjustment)
Auto Sync function works when detecting input signal
after the projector turns on.
Press AUTO SYNC to manually adjust with
Auto Sync function.
Note
When the optimum image cannot be achieved
with Auto Sync adjustment, use manual adjust-
ments. (See page 41.)
•
•
1
2
Selecting the Picture Mode
You can select the appropriate picture mode for the
projected image, such as movie or video game.
Press PICTURE MODE.
When pressing PICTURE MODE, the picture mode
changes in the following order:
NaturalStandard Dynamic
Movie2Game Movie1
Note
See page 37 for details on the picture mode.
•
•
FREEZE button
AUTO SYNC button
PICTURE MODE button
Displaying the Black Screen
Temporarily
Close the lens shutter to temporarily display a black
screen.
Note
When you close the lens shutter, the projector
will be turned off automatically after about 30
minutes.
•
XV-Z17000EUS.indb28XV-Z17000EUS.indb28 2010/12/1711:16:252010/12/1711:16:25

Sharp XV-Z17000 Specifications

General

Matrix size	0.65 \
Projection distance	1.3 - 15.7 m
Vertical scan range	43 - 85 Hz
Horizontal scan range	15 - 110 kHz
Projection technology	DLP
Contrast ratio (dynamic)	40000:1
Contrast ratio (typical)	-
Screen size compatibility	40 - 500 \
Projector native resolution	1080p (1920x1080)
Aspect ratio	16:9
RS-232 ports	1
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1080 pixels
Focus	Manual
Zoom capability	Yes
Focal length range	21 - 24.2 mm
Aperture range (F-F)	2.5 - 2.7
Lamp power	250 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Supported video modes	1080i, 1080p, 480i, 480p, 540p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Built-in speaker(s)	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Noise level (economic mode)	23 dB
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8.3 W
Power consumption (typical)	353 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	335 mm
Width	400 mm
Height	100 mm
Weight	5800 g
