16:9....................................................................... 30
3D Auto Change ................................................... 55
3D Depth Adjust ................................................... 55
3D Format ............................................................. 55
3D Glasses ......................................................50-52
3D MENU ............................................................. 55
3D MENU button ............................................ 54, 55
3D ON/OFF button ......................................... 53, 54
Accessories ............................................................ 9
AC socket ............................................................. 23
Adjustment buttons ............................................. 35
Adjustment feet .................................................... 24
Advanced ............................................................. 38
All Reset ............................................................... 47
Auto Power Off ..................................................... 46
Auto Sync ............................................................. 41
AUTO SYNC button ............................................. 28
Background .......................................................... 45
Batteries ............................................................... 13
Bright .................................................................... 37
Bright Boost ......................................................... 40
Carrying handle .................................................... 11
Ceiling-mount setup ............................................. 17
CINEMA ZOOM .................................................... 30
Clock .................................................................... 41
CLR Temp (Color Temperature) ............................ 37
C.M.S. .................................................................. 38
Color ..................................................................... 37
COMPONENT button ........................................... 27
COMPONENT terminal ......................................... 19
COMPUTER button .............................................. 27
COMPUTER/COMPONENT terminal ............. 19, 21
Contrast ................................................................ 37
Detail Enhance ..................................................... 40
DNR ...................................................................... 40
Dynamic ............................................................... 37
Dynamic Range .................................................... 42
Economy Mode .................................................... 46
ECO+QUIET button .............................................. 29
Effect .................................................................... 39
ENTER button ....................................................... 35
Fan Mode ............................................................. 47
Film Mode ............................................................. 40
Focus ring ............................................................. 24
FREEZE button ..................................................... 28
Game .................................................................... 37
Gamma ................................................................. 38
HDMI1, 2 buttons ................................................. 27
HDMI1, 2 terminals ......................................... 19, 20
HEIGHT ADJUST lever ......................................... 24
H-Image Shift ................................................. 27, 43
H-Pos ................................................................... 41
Hue ....................................................................... 39
IMAGE SHIFT button ............................................ 27
INPUT button ........................................................ 27
Input Name ........................................................... 47
Invert ..................................................................... 55
IR Emitter Level .................................................... 55
IRIS1, 2 ................................................................. 38
IRIS1, 2 buttons .................................................... 29
Kensington Security Standard connector ............ 11
KEYSTONE button ............................................... 25
Index
Lamp indicator ..................................................... 60
Lamp Timer (Life) .................................................. 47
Language (on-screen display language) .............. 45
Lens shutter .............................................. 23, 28, 63
MAGNIFY buttons ................................................ 29
MENU HIDE button .............................................. 29
MENU button ........................................................ 35
MNR ..................................................................... 40
Movie1, 2 .............................................................. 37
NATIVE .................................................................. 31
Natural .................................................................. 37
ON button ............................................................. 23
One Touch Play .................................................... 46
On-screen Display ................................................ 45
Optional accessories .............................................. 9
OSD Brightness .................................................... 45
Overscan .............................................................. 43
Phase .................................................................... 41
Picture .................................................................. 37
Picture Mode ........................................................ 37
PICTURE MODE button ....................................... 28
Power cord ....................................................... 9, 23
Power indicator .............................................. 23, 60
PRJ-ADJ ............................................................... 46
PRJ mode ....................................................... 17, 45
Remote control ..................................................... 12
Remote control sensors ....................................... 13
Replacing the lamp .............................................. 62
RESIZE button ...................................................... 30
RETURN button .................................................... 35
Rotation .......................................................... 26, 45
RS-232C ............................................................... 47
RS-232C terminal ................................................. 22
Saturation ............................................................. 39
SCR-ADJ .............................................................. 43
Screen Size and Projection Distance ................... 18
Security bar .......................................................... 11
Select Color .......................................................... 39
Sharp .................................................................... 37
SIG-ADJ ............................................................... 41
Signal Info ............................................................. 42
Signal Type ........................................................... 41
SMART ZOOM ..................................................... 31
Sphere ............................................................ 26, 44
Standard ............................................................... 37
STANDBY button .................................................. 23
STANDBY/ON button ........................................... 23
S-VIDEO button .................................................... 27
S-VIDEO terminal ........................................... 19, 20
System Standby ................................................... 46
Temperature warning indicator ............................. 60
Tint ........................................................................ 37
Value ..................................................................... 39
VIDEO button ....................................................... 27
Video Setup .......................................................... 42
Video System ....................................................... 42
VIDEO terminal ..................................................... 19
Viewing Time Info ................................................. 55
V-Image Shift .................................................. 27, 43
V-Pos .................................................................... 41
ZOOM 14:9 ........................................................... 31
Zoom ring ............................................................. 24
XV-Z17000EUS.indb78XV-Z17000EUS.indb78 2010/12/1711:16:512010/12/1711:16:51

Sharp XV-Z17000 Specifications

General

Matrix size	0.65 \
Projection distance	1.3 - 15.7 m
Vertical scan range	43 - 85 Hz
Horizontal scan range	15 - 110 kHz
Projection technology	DLP
Contrast ratio (dynamic)	40000:1
Contrast ratio (typical)	-
Screen size compatibility	40 - 500 \
Projector native resolution	1080p (1920x1080)
Aspect ratio	16:9
RS-232 ports	1
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1080 pixels
Focus	Manual
Zoom capability	Yes
Focal length range	21 - 24.2 mm
Aperture range (F-F)	2.5 - 2.7
Lamp power	250 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Supported video modes	1080i, 1080p, 480i, 480p, 540p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Built-in speaker(s)	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Noise level (economic mode)	23 dB
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8.3 W
Power consumption (typical)	353 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	335 mm
Width	400 mm
Height	100 mm
Weight	5800 g
