Sharp XV-Z17000 User Manual

Appendix
-69
Control Contents Command Parameter
Return
Power ON
Standby mode
(or 30-second startup time)
S-VIDEO INPUT Picture Mode Standard V A P S _ _ _ 1
OK or ERR ERR
Natural V A P S _ _ _ 2
OK or ERR ERR
Dynamic V A P S _ _ _ 3
OK or ERR ERR
Movie1 V A P S _ _ _ 4
OK or ERR ERR
Movie2 V A P S _ _ _ 5
OK or ERR ERR
Game V A P S _ _ _ 6
OK or ERR ERR
Contrast -30 - +30 V A P I _ * * *
OK or ERR ERR
Bright -30 - +30 V A B R _ * * *
OK or ERR ERR
Color -30 - +30 V A C O _ * * *
OK or ERR ERR
Tint -30 - +30 V A T I _ * * *
OK or ERR ERR
Sharp -30 - +30 V A S H _ * * *
OK or ERR ERR
Red -30 - +30 V A R D _ * * *
OK or ERR ERR
Blue -30 - +30 V A B E _ * * *
OK or ERR ERR
CLR Temp -2 - +2 V A C T _ _ * *
OK or ERR ERR
Picture Reset V A R E _ _ _ 1
OK or ERR ERR
VIDEO INPUT Picture Mode Standard V B P S _ _ _ 1
OK or ERR ERR
Natural V B P S _ _ _ 2
OK or ERR ERR
Dynamic V B P S _ _ _ 3
OK or ERR ERR
Movie1 V B P S _ _ _ 4
OK or ERR ERR
Movie2 V B P S _ _ _ 5
OK or ERR ERR
Game V B P S _ _ _ 6
OK or ERR ERR
Contrast -30 - +30 V B P I _ * * *
OK or ERR ERR
Bright -30 - +30 V B B R _ * * *
OK or ERR ERR
Color -30 - +30 V B C O _ * * *
OK or ERR ERR
Tint -30 - +30 V B T I _ * * *
OK or ERR ERR
Sharp -30 - +30 V B S H _ * * *
OK or ERR ERR
Red -30 - +30 V B R D _ * * *
OK or ERR ERR
Blue -30 - +30 V B B E _ * * *
OK or ERR ERR
CLR Temp -2 - +2 V B C T _ _ * *
OK or ERR ERR
Picture Reset V B R E _ _ _ 1
OK or ERR ERR
RGB Frequency Check Horizontal T F R Q _ _ _ 1 kHz (***.* or ERR) ERR
Vertical T F R Q _ _ _ 2 Hz (***.* or ERR) ERR
3D On 3 D E N _ _ _ 1 OK or ERR ERR
Off 3 D E N _ _ _ 0 OK or ERR ERR
3D Format Auto 3 D F M _ _ _ 0 OK or ERR ERR
Side By Side 3 D F M _ _ _ 1 OK or ERR ERR
Top And Bottom 3 D F M _ _ _ 2 OK or ERR ERR
Invert 3 D I V _ _ _ 1 OK or ERR ERR
Lamp Timer Reset *2 L P R E 0 0 0 1 ERR OK, ERR
Note
• If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value
in the range indicated in brackets under Control Contents.
*1
For setting the projector name, send the commands in order of PJN1, PJN2 and PJN3.
*2
The Lamp Timer Reset command can only be sent in standby mode.
XV-Z17000EUS.indb69XV-Z17000EUS.indb69 2010/12/1711:16:492010/12/1711:16:49

Sharp XV-Z17000 Specifications

General

Matrix size	0.65 \
Projection distance	1.3 - 15.7 m
Vertical scan range	43 - 85 Hz
Horizontal scan range	15 - 110 kHz
Projection technology	DLP
Contrast ratio (dynamic)	40000:1
Contrast ratio (typical)	-
Screen size compatibility	40 - 500 \
Projector native resolution	1080p (1920x1080)
Aspect ratio	16:9
RS-232 ports	1
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1080 pixels
Focus	Manual
Zoom capability	Yes
Focal length range	21 - 24.2 mm
Aperture range (F-F)	2.5 - 2.7
Lamp power	250 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Supported video modes	1080i, 1080p, 480i, 480p, 540p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Built-in speaker(s)	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Noise level (economic mode)	23 dB
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8.3 W
Power consumption (typical)	353 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	335 mm
Width	400 mm
Height	100 mm
Weight	5800 g
