Shihlin electric SS2 Series User Manual

Introduction of Shihlin Inverter
Introduction of Inverter
10
3.4 Name of Each Part
3.4.1 Nameplate and model
Model
Suitable motor：0.4KW
Rated input
Rated output
(Rated output current、Rated output
voltage、Rated output frequency)
Software version
Serial NO.
3.4.2 Names of the components
TOP COVER
BASEBOARD
mounting hole
ground terminal
fan and fan guard
type nameplate
control-circuit
terminal block
CONTROL COVER
knob
LED screen
SS2 operation panel
main-cricuit
terminal block
mounting hole
Note: 1. The enlarged figure of the control-circuit terminal block is as follows:

Shihlin electric SS2 Series Specifications

General

Brand	Shihlin electric
Model	SS2 Series
Category	Inverter
Language	English
