Shihlin electric SS2 Series User Manual

Appendix 1 Parameter list
Parameter List
148
Appendix 1 Parameter list
Parameter
number
Name Setting range
Minimum
setting unit
Default value
User setting
value
Reference
page
P.0 Torque boost
0~30% 0.1% (Note) P45
P.1 Maximum frequency
0~120Hz 0.01Hz 120Hz P46
P.2 Minimum frequency
0~120Hz 0.01Hz 0Hz P46
P.3 Base frequency
0~650Hz 0.01Hz
50Hz/60Hz
(Note)
P47
P.4 Speed 1 (high speed)
0~650Hz 0.01Hz 60Hz P48
P.5 Speed 2 (medium speed)
0~650Hz 0.01Hz 30Hz P48
P.6 Speed 3 (low speed)
0~650Hz 0.01Hz 10Hz P48
P.7 Acceleration time
0~360.00s/
0~3600.0s
0.01s/0.1s
5s（3.7KW and below）
P49
10s（5.5KW）
P.8 Deceleration time
0~360.00s/
0~3600.0s
0.1s/0.01s
5s（3.7KW and below）
P49
10s（5.5KW）
P.9
Electronic thermal relay
capacity
0~500A 0.01A 0A P51
P.10
DC injection brake
operation frequency
0~120Hz 0.01Hz 3Hz P51
P.11
DC injection brake
operation time
0~60s 0.1s 0.5s P51
P.12
DC injection brake
operation voltage
0~30% 0.1% 4% P51
P.13 Starting frequency
0~60Hz 0.01Hz 0.5Hz P52
P.14 Load pattern selection
0~13 1 0 P53
P.15 JOG frequency
0~650Hz 0.01Hz 5Hz P56
P.16
JOG acceleration /
deceleration time
0~360.00s/
0~3600.0s
0.1s/0.01s 0.5s P56
P.17
Input signal across terminal
4-5 selection
0~2 1 0 P85
P.18
High-speed maximum
frequency
120~650Hz 0.01Hz 120Hz P46
