SICK C4000 Micro User Manual

Chapter 10 Operating Instructions
C4000 Micro/Basic/Basic Plus/Eco
50 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009423/YT79/2016-03-14
Subject to change without notice
Technical specifications
10.3 Table of weights
10.3.1 C4000 Basic/Micro/Eco
Weight [g] C4000 Basic/Eco Weight [g] C4000 Micro
Protective field
height [mm]
s Sender r Receiver s Sender r Receiver
150 — — 275 290
300 820 850 370 385
450 1100 1130 510 525
600 1390 1420 650 665
750 1670 1700 795 810
900 1960 1990 940 955
1050 2250 2280 1085 1100
1200 2530 2560 1235 1250
1350 2820 2850 — —
1500 3110 3140 — —
1650 3390 3420 — —
1800 3680 3710 — —
10.3.2 Deflector mirrors PNS75 and PNS125
Weight [g]
Mirror height
[mm]
PNS75 PNS125
340 1035 1580
490 1435 2190
640 1850 2820
790 2270 3450
940 2680 4080
1090 3095 4710
1240 3510 5345
1390 3925 5980
1540 4340 6610
1690 4755 7240
1840 5170 7870
Tab.
19
:
Weight of sender
and receiver
Tab.
20
:
Weight of the
deflector mirrors PNS75
and PNS125

SICK C4000 Micro Specifications

General

Type	Safety Light Curtain
Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Enclosure Rating	IP65
Resolution	14 mm
Supply Voltage	24 V DC
Synchronization	Optical
Connection	M12 connector
Standards	EN ISO 13849
Outputs	2 safety outputs (OSSDs), 1 auxiliary output
