SICK C4000 Micro User Manual

Chapter 11 Operating Instructions
C4000 Micro/Basic/Basic Plus/Eco
58 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009423/YT79/2016-03-14
Subject to change without notice
Ordering information
11.3 C4000 Eco (M12 × 4 + FE)
Part numbers for resolution and scanning range
14 mm 14 mm 30 mm
Protective field
height
[mm]
0–2,5 m 1–5 m 0–6 m
300
s 1027440
(C40S-0301AA310)
r 1027441
(C40E-0301AN310)
s 1027440
(C40S-0301AA310)
r 1027486
(C40E-0301BN310)
s 1027464
(C40S-0303AA310)
r 1027465
(C40E-0303AN310)
450
s 1027442
(C40S-0401AA310)
r 1027443
(C40E-0401AN310)
s 1027442
(C40S-0401AA310)
r 1027487
(C40E-0401BN310)
s 1027466
(C40S-0403AA310)
r 1027467
(C40E-0403AN310)
600
s 1027444
(C40S-0601AA310)
r 1027445
(C40E-0601AN310)
s 1027444
(C40S-0601AA310)
r 1027488
(C40E-0601BN310)
s 1027468
(C40S-0603AA310)
r 1027469
(C40E-0603AN310)
750
s 1027446
(C40S-0701AA310)
r 1027447
(C40E-0701AN310)
s 1027446
(C40S-0701AA310)
r 1027489
(C40E-0701BN310)
s 1027470
(C40S-0703AA310)
r 1027471
(C40E-0703AN310)
900
s 1027448
(C40S-0901AA310)
r 1027449
(C40E-0901AN310)
s 1027448
(C40S-0901AA310)
r 1027490
(C40E-0901BN310)
s 1027472
(C40S-0903AA310)
r 1027473
(C40E-0903AN310)
1050
s 1027450
(C40S-1001AA310)
r 1027451
(C40E-1001AN310)
s 1027450
(C40S-1001AA310)
r 1027491
(C40E-1001BN310)
s 1027474
(C40S-1003AA310)
r 1027475
(C40E-1003AN310)
1200
s 1027452
(C40S-1201AA310)
r 1027453
(C40E-1201AN310)
s 1027452
(C40S-1201AA310)
r 1027492
(C40E-1201BN310)
s 1027476
(C40S-1203AA310)
r 1027477
(C40E-1203AN310)
1350
s 1027454
(C40S-1301AA310)
r 1027455
(C40E-1301AN310)
s 1027454
(C40S-1301AA310)
r 1027493
(C40E-1301BN310)
s 1027478
(C40S-1303AA310)
r 1027479
(C40E-1303AN310)
1500
s 1027456
(C40S-1501AA310)
r 1027457
(C40E-1501AN310)
s 1027456
(C40S-1501AA310)
r 1027494
(C40E-1501BN310)
s 1027480
(C40S-1503AA310)
r 1027481
(C40E-1503AN310)
1650
s 1027458
(C40S-1601AA310)
r 1027459
(C40E-1601AN310)
s 1027458
(C40S-1601AA310)
r 1027495
(C40E-1601BN310)
s 1027482
(C40S-1603AA310)
r 1027483
(C40E-1603AN310)
1800
s 1027460
(C40S-1801AA310)
r 1027463
(C40E-1801AN310)
s 1027460
(C40S-1801AA310)
r 1027496
(C40E-1801BN310)
s 1027484
(C40S-1803AA310)
r 1027485
(C40E-1803AN310)
Tab.
27
:
Part numbers
C4000 Eco (M12 × 4 + FE)

SICK C4000 Micro Specifications

General

Type	Safety Light Curtain
Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Enclosure Rating	IP65
Resolution	14 mm
Supply Voltage	24 V DC
Synchronization	Optical
Connection	M12 connector
Standards	EN ISO 13849
Outputs	2 safety outputs (OSSDs), 1 auxiliary output
