Operating Instructions Chapter 10
C4000 Micro/Basic/Basic Plus/Eco
8009423/YT79/2016-03-14 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 53
Subject to change without notice
Technical specifications
10.4.3 Swivel mount bracket
Swivel mount for …
Dimension
D [mm]
Dimension
L1 [mm]
Dimension
L2 [mm]
Dimension
L3 [mm]
C4000 Basic/Eco,
PNS75 and PNS125
30.6 44.4 75 42
C4000 Micro 24 34.3 62 36
10.4.4 Side bracket
Fig.
30
:
Dimensional drawing
swivel mount bracket (mm)
Tab.
23
:
Dimensions of the
swivel mount bracket
dependent on the housing
profile
Fig.
31
:
Dimensional drawing,
side bracket (mm)
L3
L2
8
3.8
L1
D
4
4
13
Part No. 2019506
19
50
9
5.5
34.5
15
18
6
Part No. 2019659
(for
C4000
Basic/Eco and
deflector mirror PNS)
Part No. 2019649 (for C4000 Micro)
