Chapter 12 Operating Instructions
C4000 Micro/Basic/Basic Plus/Eco
66 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009423/YT79/2016-03-14
Subject to change without notice
Annex
12.2 Checklist for the manufacturer
L
Checklist for the manufacturer/OEM for the installation of
electro-sensitive protective equipment (ESPE)
The details on the items listed below must be available at the latest when the system is commissioned for
the first time, depending, however, on the various applications the requirements of which must be reviewed by the
manufacturer/OEM.
This checklist should be retained and kept with the machine documentation to serve as reference during recurring
tests.
1. Have the safety rules and regulations been observed in compliance with the directives/standards applicable to
the machine?
Yes No
2. Are the applied directives and standards listed in the declaration of conformity? Yes No
3. Does the protective device comply with the required PL/SIL claim limit and PFHd in accordance with
EN ISO 13849-1/EN 62061 and the required type in accordance with IEC 61496-1?
Yes No
4. Is the access to the hazardous area/hazardous point only possible through the protective field of the ESPE? Yes No
5. Have appropriate measures been taken to protect (mechanical protection) or monitor (protective devices) any
persons or objects in the hazardous area when protecting a hazardous area or hazardous point, and have these
devices been secured or locked to prevent their removal?
Yes No
6. Are additional mechanical protective measures fitted and secured against manipulation which prevent reaching
below, above or behind the ESPE?
Yes No
7. Has the maximum stopping and/or run-down time of the machine been measured, specified and documented (at
the machine and/or in the machine documentation)?
Yes No
8. Has the ESPE been mounted such that the required minimum distance from the nearest hazardous point has
been achieved?
Yes No
9. Are the ESPE devices correctly mounted and secured against manipulation after adjustment? Yes No
10. Are the required protective measures against electric shock in effect (protection class)? Yes No
11. Is the control switch for resetting the protective devices (ESPE) or restarting the machine present and correctly
installed?
Yes No
12. Are the outputs of the ESPE (OSSD) integrated according to required PL/SILCL compliant with
EN ISO 13849-1/EN 62061 and does the integration correspond to the comply with the circuit diagrams?
Yes No
13. Has the protective function been checked in compliance with the test notes of this documentation? Yes No
14. Are the specified protective functions effective at every operating mode that can be set? Yes No
15. Are the switching elements activated by the ESPE, e.g. contactors, valves, monitored? Yes No
16. Is the ESPE effective over the entire period of the dangerous state? Yes No
17. Once initiated, will a dangerous state be stopped when switching the ESPE on or off and when changing the
operating mode, or when switching to another protective device?
Yes No
18. Has the information label “Important Information” for the daily check been attached so that it is well visible for the
operator?
Yes No
This checklist does not replace the initial commissioning, nor the regular inspection by qualified safety personnel.
