SICK C4000 Micro User Manual

Chapter 11 Operating Instructions
C4000 Micro/Basic/Basic Plus/Eco
62 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009423/YT79/2016-03-14
Subject to change without notice
Ordering information
11.7 Deflector mirror
11.7.1 Deflector mirror PNS75 for protective field width 0 … 5.4 m (total)
Protective field height [mm] Type number Part number
300 PNS75-034 1019414
450 PNS75-049 1019415
600 PNS75-064 1019416
750 PNS75-079 1019417
900 PNS75-094 1019418
1050 PNS75-109 1019419
1200 PNS75-124 1019420
1350 PNS75-139 1019421
1500 PNS75-154 1019422
1650 PNS75-169 1019423
1800 PNS75-184 1019424
Dimensional drawing see Fig. 32 on page 54. Effect on the scanning range see Tab. 6 on
page 16.
Do not use deflector mirrors if the formation of droplets or heavy contamination of the
deflector mirrors is to be expected!
11.7.2 Deflector mirror PNS125 for protective field width 4 … 5.4 m (total)
Protective field height [mm] Type number Part number
300 PNS125-034 1019425
450 PNS125-049 1019426
600 PNS125-064 1019427
750 PNS125-079 1019428
900 PNS125-094 1019429
1050 PNS125-109 1019430
1200 PNS125-124 1019431
1350 PNS125-139 1019432
1500 PNS125-154 1019433
1650 PNS125-169 1019434
1800 PNS125-184 1019435
Dimensional drawing see Fig. 33 on page 55. Effect on the scanning range see Tab. 6 on
page 16.
Do not use deflector mirrors if the formation of droplets or heavy contamination of the
deflector mirrors is to be expected!
Tab.
31
:
Part numbers,
deflector mirror PNS75
a
WARNING
Tab.
32
:
Part numbers,
deflector mirror PNS125
a
WARNING

SICK C4000 Micro Specifications

General

Type	Safety Light Curtain
Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Enclosure Rating	IP65
Resolution	14 mm
Supply Voltage	24 V DC
Synchronization	Optical
Connection	M12 connector
Standards	EN ISO 13849
Outputs	2 safety outputs (OSSDs), 1 auxiliary output
