SICK C4000 Micro User Manual

Operating Instructions Chapter 10
C4000 Micro/Basic/Basic Plus/Eco
8009423/YT79/2016-03-14 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 49
Subject to change without notice
Technical specifications
10.2 Response time
The response time of the C4000 Basic/Micro/Eco is dependent on the number of beams
of the system.
How to determine the response time of the system:
⋅ Read the response times of the individual systems (shown on type label).
If you are planning the application without actually having any devices available, you may
also determine the response time using Tab. 17 and Tab. 18:
⋅ Read from Tab. 17 the number of beams of the intended system by means of the
protective field height and the physical resolution.
⋅ Read from Tab. 18 the response time of the system by means of the number of beams.
Number of beams for physical resolution
Protective field height
[mm]
14 mm 30 mm
150 20 8
300 40 15
450 60 23
600 80 30
750 100 38
900 120 45
1050 140 53
1200 160 60
1350 180 68
1500 200 75
1650 220 83
1800 240 90
Number of beams Response time Number of beams Response time
10 9 ms 75 14 ms
15 10 ms 80 14 ms
20 10 ms 83 14 ms
23 10 ms 90 15 ms
25 10 ms 100 16 ms
30 11 ms 105 16 ms
35 11 ms 120 17 ms
38 11 ms 135 18 ms
40 11 ms 140 19 ms
45 12 ms 150 19 ms
50 12 ms 160 20 ms
53 12 ms 165 20 ms
55 12 ms 180 22 ms
60 13 ms 200 23 ms
68 13 ms 220 24 ms
75 14 ms 240 26 ms
Note
Tab.
17
:
Number of beams
depending on the protective
field height and the physical
resolution
Tab.
18
:
Response time
depending on the number of
beams

SICK C4000 Micro Specifications

General

Type	Safety Light Curtain
Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Enclosure Rating	IP65
Resolution	14 mm
Supply Voltage	24 V DC
Synchronization	Optical
Connection	M12 connector
Standards	EN ISO 13849
Outputs	2 safety outputs (OSSDs), 1 auxiliary output
