SICK C4000 Micro User Manual

Operating Instructions Chapter 10
C4000 Micro/Basic/Basic Plus/Eco
8009423/YT79/2016-03-14 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 45
Subject to change without notice
Technical specifications
10 Technical specifications
10.1 Data sheet
Minimum Typical Maximum
General system data
Type Type 4 (IEC 61 496-1)
Safety integrity level
2)
SIL3 (IEC 61 508)
SIL claim limit
2)
SILCL3 (EN 62 061)
Category Category 4 (EN ISO 13 849-1)
Performance Level
2)
PL e (EN ISO 13 849-1)
PFHd (mean probability of a
dangerous failure per hour)
15 × 10
–9
T
M
(mission time) 20 years (EN ISO 13 849-1)
Protective field height, depending
on type
C4000 Basic/Basic Plus/Eco
300 mm to 1800 mm
C4000 Micro
150 mm to 1200 mm
Resolution, depending on type 14 mm and 30 mm
Protective field width
Resolution 14 mm
0 m 5 m
Resolution 30 mm
0 m 6 m
Protection class III (EN 61 140)
Enclosure rating IP 65 (IEC 60 529)
Supply voltage U
V
at device
3)
19.2 V 24 V 28.8 V
Residual ripple
4)
(SELV) ° 10 %
Synchronisation Optical, without separate synchronisation
Power-up delay of sender and
receiver before ready
8 s
2)
For detailed information on the exact design of your machine/system, please contact your local SICK
representative.
3)
The external voltage supply must be capable of buffering brief mains failures of 20 ms as specified in
EN 60 204-1. Suitable power supplies are available as accessories from SICK (SICK Power Supply 50 W (Part
number 7028789)/SICK Power Supply 95 W (Part number 7028790)).
4)
Within the limits of U
V
.
Tab.
16
:
Technical data
C4000 Basic/Micro/Eco

SICK C4000 Micro Specifications

General

Type	Safety Light Curtain
Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Enclosure Rating	IP65
Resolution	14 mm
Supply Voltage	24 V DC
Synchronization	Optical
Connection	M12 connector
Standards	EN ISO 13849
Outputs	2 safety outputs (OSSDs), 1 auxiliary output
