Operating Instructions Chapter 1
DME5000
8009813/ZJV1/2017-05 © SICK AG • Germany • Subject to change without notice 75
Icons and Abbreviations Used
1 Icons and Abbreviations Used
Refers to the display buttons in the dimensional drawing (section 9.1 "Dimensional
Drawing").
Notes explain benefits of certain settings and support you in making best use of the
DME5000.
Warning notes: Read and observe with care!
Warning notes protect from danger or help in preventing damage to the sensor.
1.1 Type Label
The type label can be used to determine the device type, serial number and part number.
