9.5 Technical Data DME5000-3xx
DME5000- 311 312 313 314 315 317
Part no. 1025244 1025245 1025252 1026002 1026003 1028247
Measuring range 0.15 … 300 m
Accuracy ± 5 mm
Repeatability
1)
2 mm
Measured value output 1 ms 2 ms 2 ms 2 ms 2 ms 2 ms
Resolution data interface (adjustable) 0.05 … 5 mm
Resolution sin/cos (adjustable) 0.25 … 4 mm
Temperature drift (typ.) 0.1 mm/K
Temperature influence 1 ppm/K
Air pressure influence 0.3 ppm/hPa
Initialization time Type. 1.5 s 900 ms
Max. movement speed 10 m/s
Supply voltage U
V
2)
DC 18 … 30 V
Residual ripple
5 V
SS
Power intake (without heating) < 250 mA at DC 24 V
Light source Laser diode (red light)
Laser class 2 (EN 60825-1/C.D.R.H.)
Service life (at 25 °C) MTTF 50.000 h
Light spot diameter/distance max. 550 mm/300 m
Switching outputs MF1, MF2 B (push/pull)
Output (MF1/MF2) HIGH: U
V
‒ (< 3 V); LOW < 2 V
Input (MF1)
HIGH: > 12 V; LOW < 3 V
Output current
100 mA (short-circuit proof, overload proof)
Interfaces SSI PROFIBUS
12
MBd
RS-422 DeviceNet 500 kBd Hiperface
Operating ambience temperature –10 … +55 °C
Storage temperature –25 … +75 °C
Heating DME5000 321 322 323 324 Not
available
327
Part no. 1025246 1025247 1025253 1026004 1028248
Operating ambience temperature –40 … +55 °C
Power intake (with heating) < 1,000 mA at DC 24 V
Protection type IP 65
Electrical protection class VDE class 2 (rated voltage 32 V)
EMC EN 61000-6-2, EN 55011: Class B
Mechanic load Shock: EN 600 68-2-27/-2-29; Sine: EN 600 68-2-6; Noise: EN 600 68-2-64
Weight approx. 1650 g
1)
Statistic error 1 σ, ambience conditions consistent at minimum activation time: 10 min
2)
Protected against polarity reversal
3)
U
V
tolerances must not be exceeded or undercut
4)
Not protected against polarity reversal
5)
Max. 100 nF/20 mH
