SICK DME5000 User Manual

Operating Instructions Chapter 13
DME5000
8009813/ZJV1/2017-05 © SICK AG • Germany • Subject to change without notice 125
Annex
13.2.2 Data Format Master to DME
(DDLM_Data_Exchange)
Active (1) Inactive (0)
Encoder profile Bit 31 Preset version
Bit 30 ... 0 Preset value Unit according to resolution. Value range
+/–250 m
SICK profile Active (1) Inactive (0)
Bit 31 Preset version
Bit 30 Not assigned Not assigned
Bit 29 Laser off Laser on
Bit 25 ... 28 Not assigned Not assigned
Bit 24 ... 0 Preset value´ Unit according to resolution.
Value range +/–250 m
13.2.3 Diagnosis Data (for Activated Parameter "Extended Diagnostics")
(DDLM_Slave_Diag)
Encoder profile Diagnosis
Class 1 Octet 1 ... 16 Octet 7 ... 16
Class 2 Octet 1 ... 63 Octet 7 ... 63
Octet Active (1) Inactive (0)
Octet 1 … 6 DP standard diagnosis
Octet 7 Diagnostic Header
Octet 8
Alarms
Bit 0 Measuring error
Bit 3 Pre-failure message
Bit 4 Device error
Bit 1, 2, 5,
6, 7
Not assigned
Octet 9
Operating Status
Bit 1 Class 2 Class 1
Bit 6 Extended Diagnostics Normal Diagnostics
Bit 7 Preset-Mode: Parameter
offset is ignored
Parameter offset is
accepted
Bit 0, 2, 3,
4, 5
Not assigned
Octet 10 Encoder Type 7
Octet 11 … 14 Measuring step (linear)
Octet 15 … 16 Not assigned
