Operating Instructions Chapter 13
DME5000
8009813/ZJV1/2017-05 © SICK AG • Germany • Subject to change without notice 131
13.6.3 Examples for Commands (Standard Protocol)
Request measured value
for the DME <STX>0122<ETX>
from the DME <STX>8122<[sign]><7*[0...9]><ETX>
example: 5,378.8 mm <STX>8122+0053788<ETX>
Request reception level
for the DME <STX>0123<ETX>
from the DME
1)
<STX>8123<2*[0...F]><ETX>
example: ‒39 dB <STX>8123D9<ETX (0x100-0xD9=0x27=39)
Request internal temperature
for the DME <STX>0126<ETX>
from the DME
1)
<STX>8126<2*[0...F]><ETX>
example: +45 ℃ <STX>81262D<ETX
example: ‒10 °C <STX>8126F6<ETX (0x100-0xF6=0x0A=10)
Request speed
for the DME <STX>0135<ETX>
from the DME
1)
<STX>8135<4*[0...F]><ETX>
example: +2.8 m/s <STX>8135001C<ETX>
Request service status
for the DME <STX>0125<ETX>
from the DME <STX>8125<2*[0...F]><ETX>
example: MF2 a. PLB visible in display <STX>812582<ETX> (0x82=10000010)
MF2 MF1 TMP LSR BUS ATT PLB RDY
1 0 0 0 0 0 1 0
Continuous measured value output on
for the DME <STX>052201<ETX>
from the DME <STX>852201<ETX>
then continuous from the DME <STX>0322<[sign]><7*[0...9]><ETX>
example: 5,378.8 mm <STX>0322+0053788<ETX>
Continuous measured value output off
for the DME <STX>052200<ETX>
from the DME <STX>852200<ETX>
Continuous speed output on
for the DME <STX>053501<ETX>
from the DME <STX>853501<ETX>
then continuous from the DME <STX>0335<4*[0...F]><ETX>
example: +2.8 m/s <STX>0335001C<ETX>
Continuous speed output off
for the DME <STX>053500<ETX>
from the DME <STX>853500<ETX>
1)
Negative values are displayed as complement of 2.
