SICK MLG-2 - Application 1

5.1.1 Application 1
MLG-1
1
A
MLG-1
2
3 4
MLG-2
1
2
M12; 5pin
M12; 4pin
M12; 8pin
A
MLG-2
3 4
273 (10.75)
34
(1.34)
16.1
(0.63)
15 (0.56)
34 (1.36)
9 (0.35)
25
(0.98)
29
(1.14)
21 (0.83)
15 (0.56)
34 (1.36)
192 (7.56)
216 (8.50)
Figure 4: Application 1 – Comparison of distance between first beam and lower edge of housing on MLG-1 and MLG-2
1
Detection height
2
Beam separation
3
Receiver
4
Sender
A Distance between lower edge of housing and first beam (see table 10, page 15)
5 MOUNTING
12
