SICK MLG-2 - Electrical Connection; Overview of Accessories Required; Accessories Required

6 Electrical connection
6.1 Overview of accessories required
SICK offers some accessories in case you want to use your MLG-1 connecting cables
for the MLG-2.
Table 13: Accessories required
MLG-1 MLG-2 Accessories required for the MLG-2
Type code
Interface and connection
type
Type code
Version and data interface
Sender Receiver
MLGx-xxxxA8xx MLGxxA-xxxxBxxxxx Adapter cable
Part number: 6057015
Adapter cable
Part number: 6057014
MLGx-xxxxC8xx MLGxxN-xxxxCxxxxx No accessories required No accessories required
MLGx-xxxxE2xx (with terminal
compartment)
MLGxxN-xxxxUxxxxx M12 female connector, 5-pin,
A-coded DOS-1205-G
Part number: 6009719
“AFB” terminal box
Part number: 2082790
Included with delivery
MLGx-xxxxE5xx MLGxxA-xxxxRxxxxx No accessories required Adapter cable
Part number: 6057013
MLGx-xxxxE8xx MLGxxA-xxxxRxxxxx Adapter cable
Part number: 6057015
Adapter cable
Part number: 6057014
MLGx-xxxxF2xx (with terminal
compartment)
MLGxxN-xxxxUxxxxx M12 female connector, 5-pin,
A-coded DOS-1205-G
Part number: 6009719
“AFB” terminal box
Part number: 2082790
Included with delivery
MLGx-xxxxF5xx MLGxxA-xxxxRxxxxx No accessories required Adapter cable
Part number: 6057013
MLGx-xxxxF8xx MLGxxA-xxxxRxxxxx Adapter cable
Part number: 6057015
Adapter cable
Part number: 6057014
MLGx-xxxxI2xx (with terminal
compartment)
MLGxxN-xxxxUxxxxx M12 female connector, 5-pin,
A-coded DOS-1205-G
Part number: 6009719
“AFB” terminal box
Part number: 2082790
Included with delivery
MLGx-xxxxI8xx MLGxxA-xxxxIxxxxx Adapter cable
Part number: 6057015
Adapter cable
Part number: 6057014
MLGx-xxxxN8xx MLGxxA-xxxxBxxxxx Adapter cable
Part number: 6057015
Adapter cable
Part number: 6057014
MLGx-xxxxP8xx (PROFIBUS) MLGxxN-xxxxPxxx02 No accessories required PROFIBUS replacement mod‐
ule FBM-P22
Part number: 2092618
Included with delivery
MLGx-xxxxT2xx MLGxxN-xxxxUxxxxx M12 female connector, 5-pin,
A-coded DOS-1205-G
Part number: 6009719
“AFB” terminal box
Part number: 2082790
Included with delivery
MLGx-xxxxT8xx MLGxxA-xxxxIxxxxx Adapter cable
Part number: 6057015
Adapter cable
Part number: 6057014
Please note that the accessories are always required with the following variants:
■
MLG-1 variants with a terminal compartment: accessory required = “AFB” terminal
box
■
MLG-1 featuring PROFIBUS: accessory required = PROFIBUS replacement module
FBM-P22
