3 Response times
As the MLG-2 offers shorter response times, you may have to adjust the PLC configura‐
tion. Alternatively, you can also set a digital output delay for the MLG-2. See the relevant
MLG-2 operating instructions.
0
5
10
15
20
25
30
35
40
6 50 100 150 200 250 300 350 400 450 500
Response time in ms
Number of beams
MLG-1 / XLG
MLG-2
Figure 2: Comparison of response times for MLG-1 / XLG and MLG-2 with parallel-beam function,
MLG-2 without high-speed scan
The response time depends on the beam function and on which basic function is
selected.
In the case of the cross-beam function, multiply the response time in the diagram by 2.
RESPONSE TIMES 3
