5.1.2 Application 2
1
2
A
MLG-1
1
2
207 (8.15)
M12; 12pin
A
MLG-2
4 5 6
150 (5.91)
65 (2.56)
A
MLG-2
115 (4.53)
7
A
MLG-2
7
A
MLG-2
7
MLG-1
3 3
MLG-2
65 (2.56)
47 (1.85)
30
(1.18)
30
(1.18)
16.1
(0.63)
15 (0.56)
34 (1.36)
9 (0.35)
25
(0.98)
29
(1.14)
21 (0.83)
Figure 5: Application 2 – Comparison of distance between first beam and lower edge of housing on MLG-1 and MLG-2
1
Detection height
2
Beam separation
3
Receiver
4
“Flat” installation example
5
“Slim” installation example
6
“Compact” installation example
7
“AFB” terminal box (for additional information, see "Connecting the “AFB” terminal box", page 20).
A Distance between lower edge of housing and first beam (see table 10, page 15)
MOUNTING 5
8020351.ZLW3/2017-05-03 | SICK T E C H N I C A L I N F O R M A T I O N | The MLG-2 as a replacement product for the MLG-1 and XLG
13
Subject to change without notice
