5.1.4 Distance between lower edge of housing and first beam for all applications
Applications 1 and 3
Table 10: Applications 1 and 3 – Distance between first beam and lower edge of housing
Beam separation Dimension A
MLG-1
Dimension A
MLG-2
10 mm 40 mm 68.3 mm
20 mm 49 mm
1)
68.3 mm
59 mm
2)
78.3 mm
25 mm 64 mm 83.3 mm
30 mm 69 mm 88.3 mm
50 mm 89 mm 108.3 mm
1)
With an even number of beams
2)
With an uneven number of beams
Application 2
Table 11: Application 2 – Distance between first beam and lower edge of housing
Beam separation Dimension A
MLG-1
Dimension A
MLG-2
10 mm 160 mm 68.3 mm
20 mm 170 mm
1)
68.3 mm
180 mm
2)
78.3 mm
25 mm 175 mm 83.3 mm
30 mm 180 mm 88.3 mm
50 mm 200 mm 108.3 mm
1)
With an even number of beams
2)
With an uneven number of beams
5.2 Overview of brackets
Various brackets were available for mounting the MLG-1 light grid. In the case of the
brackets below, you can use the same mounting positions for the MLG-2 as for the
MLG-1 by relying on the BEF-1SHABP004 mounting kit.
Please note that the MLG-1 and MLG-2 differ in terms of where the first beam is
located in relation to the lower edge of the housing (see "Distance between lower edge
of housing and first beam", page 11).
