Table 4: Operating range
MLG-1 MLG-2
Operating range
Example: MLGx-xxxxxx1x
Operating range
Example: MLGxxx-xxxxxx05xx
1: 5 m, ± 3.6° 05: 5 m, ± 3.6°
2: 8.5 m, ± 3.6° 08: 8.5 m, ± 3.6°
4: 5 m, ± 5° 05: 5 m, ± 3.6°
5: 8.5 m, ± 5° 08: 8.5 m, ± 3.6°
Configuration mode → “Software Default”
The choice of variant for “Software Default” depends on the following:
■
MLG-1 configuration mode
■
The version required, which is determined by the interface and connection type of
the MLG1 (siehe Tabelle 3, Seite 5)
Table 5: Configuration mode – “Software Default”
MLG-1 MLG-2
Configuration mode
Example: MLGx-
xxxxxxxx1
Connection type
Example: MLGx-
xxxxxx5xx
Version
Example: MLGxxA-
xxxxxxxxx
Software Default
Example: MLGxxx-
xxxxxxxx01
1: Standard 5: M12, 5-pin A: Pro 97
5: M12, 5-pin N: ProNet 01
8: M12, 5-pin A: Pro 99
2: Configuration inter‐
face
8: M12, 5-pin A: Pro 99
3: Triple cross beam 5: M12, 5-pin A: Pro 96
8: M12, 5-pin A: Pro 98
L: Triple cross beam,
output Q inverted
5: M12, 8-pin A: Pro 95
Special devices, customer-specific settings or no results at all
In the following cases, please contact your SICK AG sales office:
■
Your MLG-1 is a special device: MLGx-xxxxxxxxSxx (example:
MLGx2-1180F822S01)
■
Your MLG-1 has customer-specific settings: MLGx-xxxxxxxxKxx (example:
MLGx2-0580F812K01)
■
Despite following the procedure described in this chapter, you are unable to find
an appropriate MLG-2 variant to replace your MLG-1 variant.
1.2 Finding a replacement for your XLG
Table 6: Replacement for XLG-1
XLG-1 MLG-2
Type Part number Description Result
Type code
XLG1-0590I812 1065368 Beam separation: 10 mm,
sensing range: 5 m, ± 1.8°
1 x RS-485, 1 x PNP-Out,
1 x PNP-In,
M12, 8-pin, configuration inter‐
face
MLG10A-0590I10801
1 HOW TO FIND A NEW MLG-2 LIGHT GRID AS A REPLACEMENT FOR YOUR MLG-1 OR XLG
6
T E C H N I C A L I N F O R M A T I O N | The MLG-2 as a replacement product for the MLG-1 and XLG 8020351.ZLW3/2017-05-03 | SICK
