Table 12: Replaceable MLG-1 and XLG-1 brackets
MLG-1 MLG-2
Designation Part number Description Designation Part number
Swivel mount
bracket
BEF-2SMKEAKU4
2019649 Mounting kit
BEF-1SHABP004
2071021
Side bracket
BEF-NUT-MLG
2023696
Alternatively, you can mount the MLG-2 using the following brackets:
■
FlexFix bracket BEF-1SHABPKU4 (part number: 2066614)
■
QuickFix bracket BEF-3SHABPKU2 (part number: 2066048)
In order to use this bracket, you must adapt the mounting position accordingly.
5 MOUNTING
16
T E C H N I C A L I N F O R M A T I O N | The MLG-2 as a replacement product for the MLG-1 and XLG 8020351.ZLW3/2017-05-03 | SICK
Subject to change without notice
