SICK MLG-2 - Mounting the MLG-2 with the BEF-1 SHABP004 Mounting Kit

5.2.1 Mounting the MLG-2 with the BEF-1SHABP004 mounting kit
2071021
C
A, B
1
2
5 6 7
C
A, B
A
B
3
1
2
4
103.5 (
4.07
)
7 (0.28)
8
(
0.31
)
8.4
(
0.33
)
141 (
5.55
)
196 (
7.72
)
210 (
8.27
)
8.5
(
0.335
)
7
(0.28)
141 (
5.55
)
30
(
1.18
)
Figure 7: Mounting kit (part number: 2071021) – Dimensions, layout, and scope of delivery
1
Method C
2
Method A or B
3
Screw (8x)
4
Washer (8x)
5
FlexFix bracket (4x)
6
Mounting plate (4x)
7
Sliding nut (8x)
MOUNTING 5
