SICK S3000 Cold Store - Technical data; Data sheet

12 Technical data
12.1 Data sheet
General details
T
able 28: General details
Minimum Typical Maximum
Type Type 3 (IEC 61496-1)
Safety Integrity Level
1)
SIL2 (IEC 61508)
SIL claim limit
1)
SILCL2 (EN 62061)
Category Category 3 (ISO 13849-1)
Performance level PL d (ISO 13849-1)
PFHd (T
amb
= 25 °C) (me
an probability of a danger‐
ous failure per hour)
8 × 10
–8
T
M
(mis
sion time) 20 years (ISO 13849)
Laser class Laser class 1 (according to IEC 60825-1
a
s well as CDRH 21 CFR 1040.10 and
1040.11; excluded are deviations due to
Laser Notice No. 50 dated June
24, 2007)
Enclosure rating IP65 and IP67 (EN 60529)
Protection class II (EN 50178)
2)
Operating temperature range –30 °C +50 °C
Storage temperature range –30 °C +70 °C
(
≤ 24 h)
Humidity (taking into account the operating temper‐
ature range)
IEC 614961, section 5.1.2 and 5.4.2
IEC 61496-3, section 5.4.2
Height above sea level during operation 2,300 m
Vibration IEC 61496-1, section 5.1.2 and 5.4.4.1
IE
C 614963, section 5.4.4.2
Frequency range 10 Hz 150 Hz
Amplitude 0.35 mm or 5 g
Shock resistance IEC 614961
IE
C 61496-3
Single shock 15 g, 11 ms (EN 60068-2-27)
Continuous shock 10 g, 16 ms
Sender Pulsed laser diode
Wavelength 880 nm 905 nm 935 nm
Divergence of collimated beam 2.5 mrad
Pulse duration 3.1 ns
Average output power 562 µW
Light spot size at front screen 12 mm
Light spot size at 4.0 m scanning range 23 mm
Light spot size at 5.5 m scanning range 27 mm
Light spot size at 7.0 m scanning range 32 mm
Housing
