SICK S3000 Cold Store

Minimum Typical Maximum
At 4 σ ± 80 mm
At 5 σ ± 99 mm
Flatness of the scan field at 5.5 m ± 70 mm
Flatness of the scan field at 7 m ± 88 mm
Warning field range (radial) Approx. 20
m
1)
49 m
Distance measurement range 49 m
Number of multiple samplings (can be configured
v
ia CDS)
2 16
Power-up delay 9 s 20 s
Restart after (can be configured) 2 s 60 s
1)
For objects with 20% radiance factor.
Electric
T
able 30: Electric
Minimum Typical Maximum
Safety laser scanner
Supply voltage (SELV)
1)
17.5 V 24 V 28.8 V
Permissible residual ripple ± 5%
Heating
Supply voltage (SELV) (full heating performance
only at nominal voltage)
21.6 V 24 V 26.4 V
Permissible residual ripple ± 5%
Current required, cyclic (note voltage drop on the
suppl
y cable)
4 A
Start-up current
2)
2 A
Operating current without output load
3)
0.6 A 0.8 A
Operating current with maximum output load
3)
2.2 A 2.3 A
Power consumption without output load
3)
14 W 19 W
Power consumption with maximum output load
3)
53 W 55 W
Power consumption in standby mode or park mode
w
ithout output load
14 W 19 W
Electrical connection 16-pin plug with screw-type terminals
3 × P
G11 cable gland for cable diameter
5-12 mm
Screw terminal technical data
Rigid wire cross-circuit 0.14 mm² 1.5 mm²
Flexible wire cross-circuit
4)
0.14 mm² 1.0 mm²
American wire gage (AWG) 26 16
Wire stripping length 5 mm
Screw tightening torque 0.22 Nm 0.25 Nm
Cable length for power supply tolerance ± 10%
At wire cross-section 1 mm² 50 m
with a wire cross-section of 0.5 mm² 25 m
with a wire cross-section of 0.25 mm² 12 m
Cable length for power supply tolerance ± 5%
