Dimensional drawings
160,4
100 50,9
9,5
±7,5°
±7,5°
14
1
Figure 67: Dimensional drawing adjustable bracket for S3000 Cold Store (mm)
1
35 (center of optical axis)
14.3 Additional accessories
Miscellaneous accessories
T
able 38: Ordering information, miscellaneous
Part Description Part number
Plastic cleaner Plastic cleaner and polish, anti-static 5600006
Lens cloth Cloth for cleaning the optics cover 4003353
LS80L Scan finder 6020756
Alignment aid 2101720
Drying agent cartridge with M36 × 1.5 screw-in
t
hread
5306179
