SICK S3000 Cold Store

Minimum Typical Maximum
Material Back plate and connector housing: Alu‐
minum die c
ast
Protective housing: Polyurethane (PU),
colza yellow
Color RAL 1021 (colza yellow)
Front screen
Material Polycarbonate
Interface Outside with scratch-resistant coating
System plug ESD-protected
Dimensions see "Dimensional drawings", page 119
Weight, without hardware 9 kg
1)
For detailed information on the safety configuration of the machine/system, please consult your SICK
sub
sidiary.
2)
SELV/PELV safety extra-low voltage.
Functional information
T
able 29: Functional information
Minimum Typical Maximum
Resolution 30 mm, 40 mm, 50 mm, 70 mm,
150 mm
Protective field of the sensor head with 7 m scanning range at 120 ms response time
At 30 mm resolution 2.80 m
At 40 mm resolution 3.80 m
At 50 mm resolution 4.80 m
At 70 mm resolution 7.00 m
At 150 mm resolution 7.00 m
Protective field of the sensor head with 7 m scanning range at 60 ms response time
At 30 mm resolution 1.90 m
At 40 mm resolution 2.60 m
At 50 mm resolution 3.30 m
At 70 mm resolution 4.70 m
At 150 mm resolution 7.00 m
Scanning angle 180°
Radiance factor 1.8% Several
1,000%
(r
eflectors)
Angular resolution 0.5° 0.25°
Generally necessary protective field supplement 100 mm
Supplement for retro-reflectors on scan plane with
dis
tance of less than 1 m to protective field bound‐
ary
200 mm
Measurement error for measurement data output up to 5.5 m and 1.8% radiance factor
Systematic error ± 5 mm
Statistical including systematic error
At 1 σ ± 24 mm
At 2 σ ± 43 mm
At 3 σ ± 62 mm
12 TECHNICAL DATA
