SICK S3000 Cold Store

NOTE
•
T
he heating process after switching on the device takes approx. 60 minutes at an
external temperature of –30 °C.
•
Transferring the device from a cold to a warm area can cause condensation to
form on the front screen. When this occurs, the scanner displays Í “Front screen
contaminated” and  or . In this case, a warm-up phase of up to three
hours is recommended to allow the device to reach the ambient temperature.
3.2.2 I/O module
I/O module functions
T
able 1: Functions
Function
Object resolution [mm] 30/40/50/70/150
Output signal switching device pairs (OSSDs) 1
External device monitoring (EDM)
✓
Universal I/O 3
Restart interlock/delay
✓
Field sets comprising one protective field and one warning
f
ield (dual field mode) or 2 protective fields (dual protective
field mode)
4
Can be used to simultaneously monitor 2 areas. The areas
c
an be monitored with one protective field and one warning
field respectively (dual field mode) or 2 protective fields
1)
(dual protective field mode). This allows up to 4 protective
fields to be monitored
2)
.
✓
Field sets comprising one protective field and 2 warning
fields (triple field mode) with an angular resolution of 0.5°
4
Field sets comprising one protective field and 2 warning
fields (triple field mode) with an angular resolution of
0.25°
4
Programmable monitoring cases in stand-alone operation 4
Programmable monitoring cases in an EFI system 4
Static control inputs for monitoring case switching 2
EFI interface (safe SICK device communication)
✓
Output of measurement data (surrounding contour)
✓
Extended CMS features (reflector detection, filter function
f
or measured values)
–
1)
Function is available for firmware B02.43 or above.
2)
If two or four protective fields are being monitored, the cut-off paths must be routed to independent
O
SSD pairs using a Flexi Soft safety controller.
3.2.3 Status indicators
The LEDs and 7-segment display signal the operational status of the device. They are
loc
ated on the front side of the device. Above each of the LEDs is an icon that will be
used to describe the LED in these operating instructions.
3 P
RODUCT DESCRIPTION
