SICK VMS4100 Operating Instructions

9 TECHNICAL DATA
116
8023994-17I6/2020-03-19|SICK
ORIGINAL OPERATING INSTRUCTIONS| VMS4100/5100
Subject to change without notice
Min. object size (L × W × H)
(operating condition 8)
Certified scale value
at v = 0.1 m/s to ≤ 3 m/s
200 mm x 50 mm x 20 mm / 8.0" x 2.0" x 1.0"
20 mm x 5 mm x 2 mm / 0.8" x 0.2" x 0.1"
Radiance factor 2% to 200%
Min. object gap 50 mm
Max. conveyor speed ≤ 3 m/s, start/stop operation permitted
Optical indicators 4 LEDs on the LMS4x21
Host interface Ethernet-based fieldbuses or serial RS232, 422, 485
Output data Maximum dimensions (length, width, height)
supply voltage/
power consumption
24 V DC ± 10% /
Supply voltages 230 V AC, 100 V AC ... 264 V AC
Housing Aluminum die cast
Enclosure rating/
protection class
IP 20 (in accordance with DIN 40050); with IP 65 male
connector cover
EMC test In accordance with EN 6100062:2001, EN
6100064:2001
Vibration/shock check In accordance with EN 6006826, 27, 29, 64
Weight Approx. 2.4 kg per LMS4xxx without laser protective
cover
Approx. 3.7 kg per LMS4xxx with laser protective cover
Temperature
(operation/storage)
–10 °C … +50 °C / –20 °C … +70 °C
Tab. 26: Technical data for the VMS4100/5100
